3D PARTITION

Wall Thickness

Min 10cm

Max 30cm

Wall Height

3m and above

Maximum Height

15m or above

Mesh

Galvanized Iron of 2.5 – 3 mm dia

Weight per m2

 2.5 kg

Sound Proof

Yes

MEP

Embedded

Hanging Capacity

1 construction nail (15kg)

Group of Nails (50kg)

Configuration

4cm to 15cm EPS

3cm inside concrete grout

3cm outside concrete grout

Durability

7 days minimum 2.5 N/mm2

28 days minimum 6.0 N/mm2

Area of application

Used for schools, airports, warehouses, Medical centers & commercial buildings.
